Purported iPhone 5S Logic Board Photo Leaked

iphone_5s_5_logic_boards_front

MacRumors via Macotakara, has published an alleged photo of the main board of the next-generation iPhone 5S.

Key highlights from the report:

  • The top part portion of the iPhone 5S motherboard has a larger extension that that of the iPhone 5
  • The shape of the board is nearly identical to that of the iPhone 5 logic board, with slightly different curve along the bottom edge.
  • There are no chips or other components attached to the board, although it does contain a somewhat different placement of screw holes and a tweaked chip layout.
  • The main A-series chip appears as if it will be slightly larger in area than the A6 seen in the iPhone 5, as it takes up a greater width of the logic board.

iphone_5s_5_logic_board_rear
